Beschreibung
|
Nennweite Ø (mm) |
Anschluss size |
Ausführung edition |
R (mm) |
Art.-Nr. |
| 100 | 4“ | 30° | 275 | 6085-10030027540 |
| 100 | 4“ | 30° | 1000 | 6085-10030100040 |
| 100 | 4“ | 45° | 275 | 6085-10045027540 |
| 100 | 4“ | 45° | 1000 | 6085-10045100040 |
| 100 | 4“ | 90° | 275 | 6085-10090027540 |
| 100 | 4“ | 90° | 1000 | 6085-10090100040 |
| 100 | 4 ½“ | 30° | 275 | 6085-10030027545 |
| 100 | 4 ½“ | 30° | 1000 | 6085-10030100045 |
| 100 | 4 ½“ | 45° | 275 | 6085-10045027545 |
| 100 | 4 ½“ | 45° | 1000 | 6085-10045100045 |
| 100 | 4 ½“ | 90° | 275 | 6085-10090027545 |
| 100 | 4 ½“ | 90° | 1000 | 6085-10090100045 |
| 100 | Nut/Feder – Female/Male | 30° | 275 | 6085-100320027590 |
| 100 | Nut/Feder – Female/Male | 30° | 1000 | 6085-10030100090 |
| 100 | Nut/Feder – Female/Male | 45° | 275 | 6085-10045027590 |
| 100 | Nut/Feder – Female/Male | 45° | 1000 | 6085-10045100090 |
| 100 | Nut/Feder – Female/Male | 90° | 275 | 6085-10090027590 |
| 100 | Nut/Feder – Female/Male | 90° | 1000 | 6085-10090100090 |
|
Nennweite Ø (mm) |
Anschluss size |
Ausführung edition |
R (mm) |
Art.-Nr. |
| 125 | 5“ | 30° | 275 | 6085-12530027550 |
| 125 | 5“ | 30° | 1000 | 6085-12530100050 |
| 125 | 5“ | 45° | 275 | 6085-12545027550 |
| 125 | 5“ | 45° | 1000 | 6085-12545100050 |
| 125 | 5“ | 90° | 275 | 6085-12590027550 |
| 125 | 5“ | 90° | 1000 | 6085-12590100050 |
| 125 | 5 ½“ | 30° | 275 | 6085-12530027555 |
| 125 | 5 ½“ | 30° | 1000 | 6085-12530100055 |
| 125 | 5 ½“ | 45° | 275 | 6085-12545027555 |
| 125 | 5 ½“ | 45° | 1000 | 6085-12545100055 |
| 125 | 5 ½“ | 90° | 275 | 6085-12590027555 |
| 125 | 5 ½“ | 90° | 1000 | 6085-12590100055 |
| 125 | Nut/Feder – Female/Male | 30° | 275 | 6085-12530025090 |
| 125 | Nut/Feder – Female/Male | 30° | 1000 | 6085-12530100090 |
| 125 | Nut/Feder – Female/Male | 45° | 275 | 6085-12545025090 |
| 125 | Nut/Feder – Female/Male | 45° | 1000 | 6085-1245100090 |
| 125 | Nut/Feder – Female/Male | 90° | 275 | 6085-125900250990 |
| 125 | 90° | 1000 | 6085-12590100090 |
|
Nennweite Ø (mm) |
Anschluss size |
Ausführung edition |
R (mm) |
Art.-Nr. |
| 150 | 6“ | 45° | 230 | 6085-15045023060 |
| 150 | 6“ | 45° | 1000 | 6085-15045100060 |
| 150 | 6“ | 90° | 240 | 6085-15090023060 |
| 150 | 6“ | 90° | 1000 | 6085-15090100060 |
| 150 | Nut/Feder – Female/Male | 45° | 230 | 6085-15045023090 |
| 150 | Nut/Feder – Female/Male | 45° | 1000 | 6085-15045100090 |
| 150 | Nut/Feder – Female/Male | 90° | 230 | 6085-15090023090 |
| 150 | Nut/Feder – Female/Male | 90° | 1000 | 6085-15090100090 |
| 180 | Nut/Feder – Female/Male | 90° | 270 | 6085-18090027090 |
